减压阀
时间：2019-11-14 15:45:47 作者：
减压阀
Pressure reducing valve
应用范围
- 实验室、半导体
- 分析仪器、特殊气体系统
技术参数
最大进口压力：6000PSI(413)bar
最大出口压力：3600PSI(248)bar
最高工作温度：-10℉(-23℃)至400℉(204℃)
176℉(80℃)带PCTFE阀座
392℉(200℃)带PCTFE阀座
特点:
- 波纹无穿孔隔膜
- 金属对金属隔膜密封
- 内部容积小
- 两件式阀盖设计使隔膜密封随线性负载
- 进口内有稳固固定的高流量
Applications
- Laboratory,semiconductor
- analytical instrument,special gas system
Specifications
- Inlet mas working pressure:6000PSI(413)bar
- Outlet mas working pressure:3600PSI(248)bar
- Max working temperature:
176℉(80℃)with PCTFE seat
392℉(200℃)with PEEK seat Features
Features
- Corrugated non-jperforated diaphragm
- metal-to-metal seal diaphragm seal
- Small internal vlume
- Two-piece cap design provides linear load on the diaphragm seal
- High-flow,dual-gauge type fillter positively retained in inlet port
